moedel escape route sign 'Emergency exit left arrow down', according to ISO 7010 E001, aluminum 1.8 mm, photoluminescent, W 594 x H 297 mm

This photoluminescent escape route sign indicates an escape route with the direction 'Emergency exit left' and an arrow pointing downwards. The photoluminescent coating ensures high visibility even in the event of a power failure and improves orientation in emergencies. The combination sign shows both symbols without a light edge so that the display remains clear and intuitive. The robust aluminum construction makes the sign durable and resistant.

The large dimensions of 594 x 297 mm make it particularly suitable for spacious buildings and large rooms where clearly visible escape route signage is required. The standard-compliant design ensures that the direction of the escape route is quickly identified.

Important details:

• Combination sign with directional arrow pointing downwards and emergency exit on the left
• Symbols: 'Down arrow' and 'Emergency exit left' (E001)
• Safety message from the observer's point of view:
  • Go down (indicate floor change)
  • Previous practical use: go straight ahead / go through a door
• Material: Aluminum, 1.8 mm thick
• Format: W 594 x H 297 mm
• Luminance: 160 mcd/m²
• Complies with luminance class C according to DIN 67510 / ISO 17398
• Standards:
  • DIN EN ISO 7010 (E001) → Standard for emergency exit signage
  • DIN ISO 3864 → Safety colors & signs
  • DIN ISO 16069 → Escape route marking
  • ASR A1.3 (2013) → Technical rules for workplaces

Places of use:

• Escape and rescue routes in large buildings
• Spacious halls, warehouses and production facilities
• Public buildings with high safety requirements
