moedel escape route sign 'Emergency exit left arrow down', according to DIN EN ISO 7010 E001, aluminum 0.6 mm, photoluminescent, W 297 x H 148 mm

This photoluminescent escape route sign ensures that emergency exits are clearly marked. The combination of a directional arrow pointing downwards and the 'Emergency exit left' symbol (E001) ensures quick orientation. The robust aluminum construction with a thickness of 0.6 mm is durable and resistant. Thanks to the photoluminescent coating, the marking remains clearly visible even in poor lighting conditions or in the event of a power failure.

The clear safety message enables intuitive use: either for changing floors downwards or as an indication of a direct escape route through a door. The sign complies with the relevant standards and is suitable for professional use in public buildings, businesses or industrial halls.

Important details:

• Combination sign without a light edge between the symbols
• Symbols: 'Directional arrow down' and 'Emergency exit left' (E001)
• Safety message from the observer's point of view:
  • Go down (indicate floor change)
  • Alternative use: Straight ahead / doorway
• Material: Aluminum, 0.6 mm thick
• Format: W 297 x H 148 mm
• Luminance: 160 mcd/m²
• Complies with luminance class C according to DIN 67510 / ISO 17398
• Standards:
  • DIN EN ISO 7010 (E001) → Standard for emergency exit signs
  • DIN ISO 3864 → Safety colors & signs
  • DIN ISO 16069 → Escape route marking
  • ASR A1.3 (2013) → Technical rules for workplaces

Places of use:

• Escape and rescue routes in multi-storey buildings
• Stairwells & emergency exits in industrial halls, offices, shopping centers
• Buildings with several floors or complex escape route structures
