moedel escape route sign 'Emergency exit left arrow down', according to ISO 7010 E001, plastic self-adhesive, photoluminescent, W 297 x H 148 mm

This photoluminescent escape route sign indicates the emergency exit to the left with a directional arrow pointing downwards. The photoluminescent coating ensures clear visibility even in the event of a power failure and helps to intuitively identify escape routes. The combination sign combines the symbols for 'Emergency exit left' (E001) and 'Direction arrow down' without a distracting light edge to enable clear orientation.

Thanks to the self-adhesive plastic surface, the sign can be easily attached to walls or doors. Ideal for stairwells, emergency exits and other areas with multi-storey escape routes to indicate the safe way down.

Important details:

• Combination sign without light edge
• Symbols: 'Directional arrow down' & 'Emergency exit left' (E001)
• Safety message from the recipient's point of view:
  • Go downwards (floor change)
  • Alternative use: Straight ahead / doorway
• Material:
  • Plastic: plasticizer-free rigid polyvinyl chloride (PVC-U)
  • self-adhesive
• Format: W 297 x H 148 mm
• Luminance: 160 mcd/m²
• Complies with luminance class C according to DIN 67510 / ISO 17398
• Standards:
  • DIN EN ISO 7010 (E001) - Standard for emergency exit signs
  • DIN ISO 3864 - Safety colors & signs
  • DIN ISO 16069 - Escape route marking
  • ASR A1.3 (2013) - Technical rules for workplaces

Places of use:

• Escape and rescue routes with height differences
• Stairwells in public buildings & workplaces
• Emergency exits in industrial halls, offices & shopping centers
