moedel escape route sign 'Emergency exit left arrow down', according to ISO 7010 E001, plastic self-adhesive, photoluminescent, W 400 x H 200 mm

Article numbers

663781 663796 663823 663830 663844 663872 663876 663901 663932

moedel escape route sign 'Emergency exit left arrow down', according to ISO 7010 E001, plastic self-adhesive, photoluminescent, W 400 x H 200 mm

Item number: 663781

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

This photoluminescent escape route sign ensures that emergency exits and escape routes are clearly marked. The combination of a directional arrow pointing downwards and the emergency exit symbol in accordance with ISO 7010 (E001) enables quick orientation in an emergency. Thanks to the photoluminescent surface, the sign remains clearly visible even in the event of a power failure. It is suitable for various areas of application and can be easily attached to smooth surfaces thanks to the self-adhesive back.

Important details:

Combination sign with directional arrow pointing downwards and emergency exit on the left
Symbols: 'Down arrow' and 'Emergency exit left' (E001)
Safety message from the observer's point of view:
- Go down (indicate floor change)
- Previous practical use: go straight ahead / go through a door
Material:
- Plastic: plasticizer-free rigid polyvinyl chloride (PVC-U)
- self-adhesive
Format: W 400 x H 200 mm
Luminance: 160 mcd/m²
Complies with luminance class C according to DIN 67510 / ISO 17398
Standards:
- DIN EN ISO 7010 (E001) → Standard for emergency exit signage
- DIN ISO 3864 → Safety colors & signs
- DIN ISO 16069 → Escape route marking
- ASR A1.3 (2013) → Technical rules for workplaces

Places of use:

Escape and rescue routes in multi-storey buildings
Stairwells & emergency exits in industrial halls, offices, shopping centers
Buildings with several floors or complex escape route structures

Show moreShow less

Technical data

General features
Form Rectangle
Material Polyvinyl chloride (PVC)
Mounting type self-adhesive
Photoluminescent Yes
Print Emergency exit left Arrow down
Self-adhesive Yes
Shield type Wall mounting
Standard DIN 67510;DIN EN ISO 7010;DIN ISO 16069;DIN ISO 3864;ISO 17398
Weatherproof Yes
Colors
Color green
Dimensions
Width [mm] 400

Download

ProductSafety_10183800.pdf

Schäfer Shop Quality and Service

Special features of this product

only Fr. 32.10

per

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Material: Polyvinyl chloride (PVC)

Polyvinyl chloride (PVC) Aluminium Slide Plastic

Width [mm]: 400 mm

400 mm 297 mm 594 mm

show all variants

Add to basket

Delivery time: within 2 weeks

Purchase on account available
Secure and fast payment

Our recommendations for you

Variants

Overview of variants - moedel escape route sign "Emergency exit left arrow down", to ISO 7010 E001, photoluminescent, choice of variants

Overview of the possible item variants. For more information, click on the respective variant.

Material

Width [mm]

Item			Price
moedel escape route sign 'Emergency exit left arrow down', according to ISO 7010 E001, plastic self-adhesive, photoluminescent, W 400 x H 200 mm Item number: 663781			Fr. 32.10 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to DIN EN ISO 7010 E001, aluminum 0.6 mm, photoluminescent, W 297 x H 148 mm Item number: 663796			Fr. 18.55 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to ISO 7010 E001, self-adhesive film, photoluminescent, W 297 x H 148 mm Item number: 663823			Fr. 15.55 Amount + - Added times
moedel escape route sign "Emergency exit left", to ISO 7010 E001, plastic, photoluminescent, W 400 x H 200 mm Item number: 663830			Fr. 29.10 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to ISO 7010 E001, plastic, photoluminescent, W 297 x H 148 mm Item number: 663844			Fr. 17.55 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", to ISO 7010 E001, self-adhesive film, photoluminescent, W 400 x H 200 mm Item number: 663872			Fr. 29.10 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to ISO 7010 E001, aluminum 0.6 mm, photoluminescent, W 400 x H 200 mm Item number: 663876			Fr. 32.10 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to ISO 7010 E001, plastic self-adhesive, photoluminescent, W 297 x H 148 mm Item number: 663901			Fr. 18.55 Amount + - Added times
moedel escape route sign "Emergency exit left arrow down", according to ISO 7010 E001, aluminum 1.8 mm, photoluminescent, W 594 x H 297 mm Item number: 663932			Fr. 72.95 Amount + - Added times
