Product Safety Information

Sump tray Bauer AWA 32, steel, hot-dip galvanized, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling tops, 1 grate

General information

Product safety instructions

Use suitable personal protective equipment (PPE), such as gloves and safety goggles, when handling harmful hazardous substances.;Make sure that the drip tray is stable and level to prevent it from tipping over, overflowing or slipping.;Regularly check the integrity of the drip tray and the IBC containers to prevent leaks. Regular inspections of the wall structure and functionality are essential.;Keep flammable materials away from the product and the operating environment to minimise the risk of fire.;Do not overload the drip tray - observe the maximum load capacity of 1000 kg/m².;Only use forklift trucks or pallet trucks in accordance with the operating instructions and suitable equipment.;In the event of large spills of hazardous substances, report them immediately to the responsible authorities.;Only suitable for the storage of IBC containers and authorised containers to prevent overflow and leakage.;If handled incorrectly, there is a risk of injury from the grating and unsafe lifting or loading of hazardous materials.;Store hazardous substances safely to prevent damage to the environment and health. Only suitable for the storage of authorised substances.

Article numbers

132887 132888 132889 132890 132891 132892

Sump tray Bauer AWA 32, steel, hot-dip galvanized, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling tops, 1 grate

Name: Sump tray Bauer AWA 32, steel, hot-dip galvanized, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling tops, 1 grate
Brand: Bauer
SKU: 7734877
Price: 4014.0 CHF
Availability: InStock

Item number: 132892

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

With the AWA 32 from Bauer including grating, you get a sump tray on which you can safely store up to 3 x 1000 litre IBC containers. Material quality is of inestimable importance when dealing with harmful hazardous materials and dangerous substances. Robust, durable sheet steel allows easy cleaning and ensures a long service life of the collection tray with hot-dip galvanised surface. For easier handling, it can be moved underneath with a pallet truck or forklift.

Possible applications of the AWA 32 sump tray from Bauer:

For storing IBC tanks of 1000 litres each.
Can also be combined with 200 and 60 litre drums and small containers

Plus points of the sump tray at a glance:

2 filling attachments
1 grid made of galvanized steel, load capacity 1000 kg/m²
Construction made of 3 mm sheet steel
Feet for 100 mm underclearance

Show moreShow less

Technical data

General features
Capacity barrels 3 x 1000 l
Capacity IBC container 3 x 1000 l
Collecting volume [l] 1000
Container type Small containers, drums, IBC containers
Grid Yes
Grid material Steel
Grid surface galvanized
Hazardous substance type Flammable liquids GHS 1-3; Substances hazardous to water GHS 1-4
Height [mm] 865
Length [mm] 3850
Load capacity (kg/m²) 1000
Material Steel
Mobile Forklift compatible
Permeable wall thickness (mm) 3
Standard declaration of conformity (ÜHP) according to StawaR
Substructure Feet
Surface hot-dip galvanized
Weight [kg] 387
Colors
Color galvanised
Dimensions
Width [mm] 1460

Download

ProductSafety_10159400.pdf

Schäfer Shop Quality and Service

Special features of this product

Danger - H410 Very toxic to aquatic life with long lasting effects.

only Fr. 4’014.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Color: galvanised

show all variants

Add to basket

Delivery time: within 4 weeks

Purchase on account available
Secure and fast payment

Variants

Overview of variants - Sump tray Bauer AWA 32, steel, orange, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 waste chutes, 1 grate

Overview of the possible item variants. For more information, click on the respective variant.

Color

Item			Price
Sump tray Bauer AWA 32, steel, orange, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 waste chutes, 1 grate Item number: 132887			Fr. 3’768.00 Amount + - Added times
Sump tray Bauer AWA 32, steel, red, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling attachments, 1 grate Item number: 132888			Fr. 3’768.00 Amount + - Added times
Collecting tray Bauer AWA 32, steel, blue, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling attachments, 1 grate Item number: 132889			Fr. 3’768.00 Amount + - Added times
Collecting tray Bauer AWA 32, steel, green, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling attachments, 1 grate Item number: 132890			Fr. 3’768.00 Amount + - Added times
Collecting tray Bauer AWA 32, steel, grey, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling attachments, 1 grate Item number: 132891			Fr. 3’768.00 Amount + - Added times
Sump tray Bauer AWA 32, steel, hot-dip galvanized, L 3850 x W 1460 x H 780 mm, 1000 l, for 3 x 1000 l IBC, 2 filling tops, 1 grate Item number: 132892			Fr. 4’014.00 Amount + - Added times
