Product Safety Information

Sump tray Bauer AWA 21, steel, red, L 2650 x W 1460 x H 863 mm, 1000 l, for 2 x 1000 l IBC, 1 filling attachment, 1 grate

General information

Product safety instructions

Do not use damaged containers or equipment.;Wear protective clothing such as gloves, safety goggles and respirators when working with hazardous materials.;Only use the drip tray for the intended substances and for non-flammable and non-aggressive substances.;Carry out regular inspections for corrosion, rust or structural damage to the drip tray.;Ensure safe access to the drip tray and keep it on a stable, level surface to prevent accidents and tipping.;Empty and clean the drip tray after use to avoid residues.;When using forklift trucks or pallet trucks, observe the load capacity of 1000 kg/m² and take safety precautions.;Carry out regular maintenance and inspections to ensure the integrity of the drip tray.;Use suitable materials and safety precautions when storing and handling hazardous substances.;Disposal of hazardous waste in accordance with applicable legal regulations.;Do not place the drip tray near heat sources, explosive materials or in direct sunlight.;Do not load the drip tray above the maximum load capacity of 1000 kg/m².;Ensure that the drip tray is only used for suitable IBC containers.;Take care when cleaning: Chemical substances can attack materials.;In the event of a leak, immediately take measures to collect and dispose of the hazardous substance.

Article numbers

132875 132876 132877 132878 132879 132880

Sump tray Bauer AWA 21, steel, red, L 2650 x W 1460 x H 863 mm, 1000 l, for 2 x 1000 l IBC, 1 filling attachment, 1 grate

Name: Sump tray Bauer AWA 21, steel, red, L 2650 x W 1460 x H 863 mm, 1000 l, for 2 x 1000 l IBC, 1 filling attachment, 1 grate
Brand: Bauer
SKU: 7720477
Price: 1897.0 CHF
Availability: InStock

Item number: 132876

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

With the AWA 21 from Bauer including grating in fire red RAL 3000, you get a sump tray on which you can safely store up to 2 x 1000 litre IBC containers. Create safety in the operational handling of hazardous substances by choosing the right material. Made of highly resistant, durable sheet steel, the drip tray with painted surface is easy to clean. To facilitate handling, it is accessible by forklift or pallet truck.

Possible applications of the AWA 21 sump tray from Bauer:

For storing IBC tanks of 1000 litres each.
Can also be combined with 200 and 60 litre drums and small containers

Plus points of the sump tray at a glance:

1 filling attachment
1 grid made of galvanized steel, load capacity 1000 kg/m²
Construction made of 3 mm sheet steel
Feet for 100 mm underclearance

Show moreShow less

Technical data

General features
Capacity barrels 2 x 1000 l
Capacity IBC container 2 x 1000 l
Collecting volume [l] 1000
Container type Small containers, drums, IBC containers
Grid Yes
Grid material Steel
Grid surface galvanised
Hazardous substance type Flammable liquids GHS 1-3; Substances hazardous to water GHS 1-4
Height [mm] 865
Length [mm] 2650
Load capacity (kg/m²) 1000
Material Steel
Mobile Forklift compatible
Permeable wall thickness (mm) 3
Standard declaration of conformity (ÜHP) according to StawaR
Substructure Feet
Surface varnished
Weight [kg] 272
Colors
Color fire red RAL 3000
Dimensions
Width [mm] 1460

Download

ProductSafety_10159398.pdf

Schäfer Shop Quality and Service

Special features of this product

Danger - H410 Very toxic to aquatic life with long lasting effects.

only Fr. 1’897.00

per Pcs.

excl. VAT free shipping from CHF 100.–
