Product Safety Information

Steel collecting pan without grid, 1800 x 800 mm, green RAL 6011

General information

Product safety instructions

The drip tray must not be filled with more liquid than the specified collection volume of 217 litres.;When handling drums, wear suitable personal protective equipment and observe safety regulations.;The tank must be checked regularly for visible damage, leaks or corrosion to ensure its integrity.;Product may only be used in well ventilated areas.;Observe the maximum storage capacity of 3 barrels of 200 litres each.;Keep product away from children, do not use toys.;Always read the operating instructions and safety information.;Ensure that the tray is standing on a stable and level surface to prevent it from tipping over.;Close the drums securely to prevent leakage.;Caution: Sheet steel can be sharp-edged.;The manufacturer must provide a declaration of conformity (ÜHP) in accordance with StawaR.

Article numbers

133031 133032 133033 133034 134870 134871

Steel collecting pan without grid, 1800 x 800 mm, green RAL 6011

Item number: 134871

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

Storage of max. 3 drums (200 litres). With declaration of conformity (ÜHP), in accordance with StawaR, for flammable liquids of GHS categories 1-3 and liquids hazardous to water of GHS categories 1-4.

Construction made of 3 mm sheet steel
100 mm underclearance
Dimensions: L 1800 x W 800 x H 275 mm
Collecting volume: 217 l
Weight: 58 kg painted / 62 kg galvanised

Show moreShow less

Technical data

General features
Accessible from below Yes
Capacity 217 litres
Collecting volume [l] 217
Container type Barrels
Grid No
Hazardous substance type Flammable liquids GHS 1-3; Substances hazardous to water GHS 1-4
Load capacity (kg/m²) 1000
Load capacity [kg] 1000/sqm
Material Steel
Mobile Forklift compatible
Number of containers 3
Permeable wall thickness (mm) 3
Stackable No
Standard declaration of conformity (ÜHP) according to StawaR
Substructure Feet
Surface varnished
Undercarriage height (mm) 100
Weight [kg] 55
Colors
Color reseda green RAL 6011
Dimensions
Depth [mm] 800
Height [mm] 275
Length [mm] 1800
Width [mm] 1800

Download

ProductSafety_10116165.pdf

Schäfer Shop Quality and Service

Special features of this product

Danger - H410 Very toxic to aquatic life with long lasting effects.

only Fr. 409.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Color: reseda green RAL 6011

show all variants

Add to basket

Delivery time: within 2 weeks

Purchase on account available
Secure and fast payment

Our recommendations for you

Variants

Overview of variants - Steel sump tray, 1800 x 800 mm

Overview of the possible item variants. For more information, click on the respective variant.

Color

Item			Price
Steel collecting pan without grid, 1800 x 800 mm, orange RAL 2000 Item number: 133031			Fr. 409.00 Amount + - Added times
Steel collecting basin without grid, 1800 x 800 mm, red RAL 3000 Item number: 133032			Fr. 409.00 Amount + - Added times
Steel collecting bucket without grid, 1800 x 800 mm, blue RAL 5012 Item number: 133033			Fr. 409.00 Amount + - Added times
Steel collecting bucket without grid, 1800 x 800 mm, galvanized Item number: 133034			Fr. 479.00 Amount + - Added times
Steel collecting pan without grid, 1800 x 800 mm, grey RAL 7005 Item number: 134870			Fr. 409.00 Amount + - Added times
Steel collecting pan without grid, 1800 x 800 mm, green RAL 6011 Item number: 134871			Fr. 409.00 Amount + - Added times
