Product Safety Information

Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, safety yellow front, W 1164 x D 620 x H 1947 mm

General information

Product safety instructions

Only store authorised chemicals to avoid risks.;The door mechanism must be functional to ensure safe closing.;Maintain the ventilation system regularly and use it correctly to minimise the risk of explosion.;Set up the cabinet in a stable and level position and anchor it to prevent it from tipping over.;Check the floor drip tray regularly for leaks and damage and replace if necessary.;Check for damage before use.;Carry out maintenance and inspection regularly in accordance with the instructions.;Do not overload the cupboard; observe the maximum load capacity of the shelves (75 kg per shelf).;If there is a risk of fire, close the cupboard and alert the local emergency services.;Ensure that the hinged doors are securely closed when not in use.;Only use for the materials specified in the operating instructions.;Only store hazardous substances in the safety cabinet provided for this purpose.;Grant access only to authorised persons and use a profile cylinder lock to prevent unauthorised access.;The load capacity of the shelves should not exceed 75 kg to avoid structural damage or accidents.;Ensure that the cabinet is operated in accordance with the safety-relevant European standards.;Risk of fire and explosion due to improper storage and handling of chemicals.;Compliance with safety regulations for the integrated ventilation system to prevent harmful vapours and explosions.;Fire-retardant cabinet (F30) should be installed in a fire-safe location.;Dispose of hazardous chemicals correctly.;Be aware of health risks due to improper handling of toxic substances and aggressive chemicals.;Regularly check and follow the technical documentation.;Use the cabinet in accordance with the GHS guidelines for hazardous chemicals and observe specific regulations.;Avoid risk of suffocation due to unsupervised storage.;Do not block the exhaust air connections to ensure proper function.

Article numbers

462139 462140 462141 462142 462143 462144 462145

Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, safety yellow front, W 1164 x D 620 x H 1947 mm

Name: Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, safety yellow front, W 1164 x D 620 x H 1947 mm
Brand: Asecos
SKU: 7728577
Price: 3499.0 CHF
Availability: InStock

Item number: 462139

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

The Q-CLASSIC-30 safety cabinet model Q30.195.116 from asecos is F30 fire retardant. This product is suitable for the storage of toxic substances or other aggressive chemicals, flammable liquids of the GHS categories 1-3 and water-polluting substances of the GHS 1-4. Hinged doors, which can be locked via a profile cylinder lock, are an integral part of this safety cabinet. For a necessary explosion protection, the commissioning can be carried out on a technical exhaust air system with exhaust air connection (75 mm), which achieves a 10-fold air exchange of 9 m³/h. The safety cabinet is equipped with a safety lock. In order to facilitate handling, it can be moved underneath using a pallet truck or forklift.

The equipment of the safety cabinet includes:

4 x shelves, load capacity 75 kg, sheet steel powder-coated, RAL 7035 light grey.
1 x floor collection tray, capacity 33 litres, powder-coated sheet steel, RAL 7035 light grey

Advantages for you

With a fire resistance class F30, the safety cabinet is fire retardant for up to 30 minutes

Show moreShow less

Technical data

General features
Accessible from below Yes
Air exchange 10x (m³/h) 9
Body colour anthracite grey
Body surface Microperl
Color of the facade golden yellow RAL 1004
Delivery Mounted
Door version Hinged doors
Entry width (mm) 90
Fire resistance class F30 fire retardant
Front panel material Sheet steel
GS-approved Yes
Hazardous material class Aggressive chemicals;Flammable liquids;Substances hazardous to water
Hazardous substance type Aggressive chemicals; Flammable liquids of GHS categories 1-3; Substances hazardous to water GHS 1-4; Toxins
Height of the entrance (mm) 1012
Lockable Yes
Locking system profile cylinder lock
Material body Special material sheets
Max. load capacity (kg) 600
Model Q30.195.116
Shelf load capacity [kg] 75,00
Standard EN 16121;EN 16122;EN-14470-1
Substructure Integrated transport base
Surface front structured
Surface load (kg/m) 445
Ventilation Exhaust air connection (75 mm)
Weight [kg] 259,00

Schäfer Shop Quality and Service

Special features of this product

Danger - H314 Causes severe skin burns and eye damage.

Danger - H410 Very toxic to aquatic life with long lasting effects.

Danger - H300 Danger to life if swallowed. H310 Danger to life in case of skin contact. H330 Danger to life by inhalation.

only Fr. 3’499.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Color of the facade: golden yellow RAL 1004

show all variants

Add to basket

Delivery time: approx. 16 weeks

Purchase on account available
Secure and fast payment

Variants

Overview of variants - Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, W 1164 x D 620 x H 1947 mm

Overview of the possible item variants. For more information, click on the respective variant.

Color of the facade

Item			Price
Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, safety yellow front, W 1164 x D 620 x H 1947 mm Item number: 462139			Fr. 3’499.00 Amount + - Added times
Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, front light grey, W 1164 x D 620 x H 1947 mm Item number: 462140			Fr. 3’499.00 Amount + - Added times
Safety storage cabinet type 30 asecos Q-CLASSIC-30, hinged doors, traffic red front, W 1164 x D 620 x H 1947 mm Item number: 462141			Fr. 3’499.00 Amount + - Added times
Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, gentian blue front, W 1164 x D 620 x H 1947 mm Item number: 462142			Fr. 3’499.00 Amount + - Added times
Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, reseda green front, W 1164 x D 620 x H 1947 mm Item number: 462143			Fr. 3’499.00 Amount + - Added times
Safety cabinet type 30 asecos Q-CLASSIC-30, hinged doors, silver front asecos, W 1164 x D 620 x H 1947 mm Item number: 462144			Fr. 3’499.00 Amount + - Added times
Safety storage cabinet type 30 asecos Q-CLASSIC-30, hinged doors, front pure white, W 1164 x D 620 x H 1947 mm Item number: 462145			Fr. 3’499.00 Amount + - Added times
No results

Accessories

Item			Price
Ventilation overlay for hazardous material cabinets VBF.196.60 and VBF.196.120 Item number: 22093			only Fr. 1’077.00 from Fr. 1’077.00 per Pcs. Go to product
Air filtering element for air circulation asecos Item number: 131996			only Fr. 2’373.00 from Fr. 2’373.00 per Pcs. Go to product
Q-Mover transport trolley Item number: 131997			only Fr. 247.00 from Fr. 247.00 per set Go to product
Trough base for Hazardous Material Cabinet Type 90, 435 x 1045 mm, light grey Item number: 22100			only Fr. 69.50 from Fr. 69.50 per Pcs. Go to product
Ventilation overlay for wall units, with exhaust air monitoring, W 200 x D 400 x H 200 mm Item number: 138914			only Fr. 1’245.00 from Fr. 1’245.00 per Pcs. Go to product
Standard shelf for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4301, W 1043 x D 435 x H 30 mm, up to 75 kg Item number: 461747			only Fr. 155.00 from Fr. 155.00 per Pcs. Go to product
Standard tray for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1042 x D 462 x H 80 mm, 33 l, up to 150 kg Item number: 461748			only Fr. 76.85 from Fr. 76.85 per Pcs. Go to product
Standard tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4016, W 1042 x D 462 x H 80 mm, 33 l, up to 150 kg Item number: 461749			only Fr. 194.00 from Fr. 194.00 per Pcs. Go to product
Standard tray for asecos safety cabinets of the Q30, Q90 and S90 series, polypropylene, grey, W 955 x D 485 x H 112 mm, 33 l, up to 50 kg Item number: 461750			only Fr. 325.00 from Fr. 325.00 per Pcs. Go to product
Grating for asecos safety storage cabinets of the Q30, Q90 and S90 series, steel, W 1036 x D 450 x H 30 mm, up to 180 kg Item number: 461751			only Fr. 187.00 from Fr. 187.00 per Pcs. Go to product
Perforated sheet insert Standard for asecos safety cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1017 x D 482 x H 66 mm, up to 75 kg Item number: 461752			only Fr. 76.85 from Fr. 76.85 per Pcs. Go to product
Perforated plate insert standard for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4016, W 1017 x D 482 x H 66 mm, up to 75 kg Item number: 461753			only Fr. 142.00 from Fr. 142.00 per Pcs. Go to product
Perforated sheet insert Standard for asecos safety cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1009 x D 474 x H 111 mm, up to 75 kg Item number: 461754			only Fr. 272.00 from Fr. 272.00 per Pcs. Go to product
STAWA-R floor collection tray for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1042 x D 507 x H 86 mm, 33 l Item number: 461755			only Fr. 89.85 from Fr. 89.85 per Pcs. Go to product
STAWA-R floor collecting tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4016, W 1042 x D 507 x H 86 mm, 33 l Item number: 461756			only Fr. 219.00 from Fr. 219.00 per Pcs. Go to product
STAWA-R floor collection tray for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1042 x D 507 x H 131 mm, 55 l Item number: 461757			only Fr. 105.00 from Fr. 105.00 per Pcs. Go to product
Standard floor collecting tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4016, W 1042 x D 462 x H 122 mm, 55.5 l Item number: 461758			only Fr. 325.00 from Fr. 325.00 per Pcs. Go to product
STAWA-R floor collection tray for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 1042 x D 507 x H 86 mm, 33 l Item number: 461759			only Fr. 76.85 from Fr. 76.85 per Pcs. Go to product
STAWA-R floor collecting tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4016, W 1042 x D 507 x H 86 mm, 33 l Item number: 461760			only Fr. 158.00 from Fr. 158.00 per Pcs. Go to product
Bottom sump tray Abz for asecos safety storage cabinets of the Q30, Q90 and S90 series, polypropylene, grey, W 1049 x D 505 x H 116 mm, 33 l Item number: 461761			only Fr. 170.00 from Fr. 170.00 per Pcs. Go to product
Standard pull-out tray for asecos safety cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 864 x D 508 x H 90 mm, 29 l, up to 60 kg Item number: 461762			only Fr. 320.00 from Fr. 320.00 per Pcs. Go to product
Standard pull-out tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4301, W 864 x D 508 x H 90 mm, 29 l, up to 60 kg Item number: 461763			only Fr. 440.00 from Fr. 440.00 per Pcs. Go to product
Heavy-duty pull-out tray for asecos safety cabinets of the Q30, Q90 and S90 series, stainless steel 1.4301, W 864 x D 508 x H 162 mm, 66 l, up to 100 kg Item number: 461765			only Fr. 858.00 from Fr. 858.00 per Pcs. Go to product
Storage box for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 380 x D 420 x H 360 mm, door hinge left Item number: 461766			only Fr. 286.00 from Fr. 286.00 per Pcs. Go to product
Storage box for asecos safety storage cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 380 x D 420 x H 360 mm, door hinge right Item number: 461767			only Fr. 286.00 from Fr. 286.00 per Pcs. Go to product
Insert tray for asecos safety cabinets of the Q30, Q90 and S90 series, polyethylene, black, W 1043 x D 435 x H 50 mm, 18 l Item number: 461768			only Fr. 102.85 from Fr. 102.85 per Pcs. Go to product
Insert tray for asecos safety cabinets of the Q30, Q90 and S90 series, polypropylene, grey, W 878 x D 500 x H 96 mm, 33.5 l Item number: 461769			only Fr. 182.00 from Fr. 182.00 per Pcs. Go to product
Pipe bushing for asecos safety cabinets of the Q30, Q90 and S90 series, sheet steel, light grey, W 182 x D 104 x H 48 mm Item number: 461771			only Fr. 129.00 from Fr. 129.00 per Pcs. Go to product
Chemical box for asecos safety and chemical cabinets, polypropylene, blue, W 410 x D 300 x H 260 mm Item number: 461772			only Fr. 96.45 from Fr. 96.45 per Pcs. Go to product
