Product Safety Information

DB700 Forklift

General information

EU authorized representative E-mail address

post@hanselifter.de

EU authorized representative Name

HanseLifter

EU authorized representative Place

Bremen

EU authorized representative Postal code

28219

EU authorized representative Street & house number

Straubinger Straße 20

EU Plenipotentiary Country

Deutschland

Manufacturer Country

Manufacturer e-mail address

post@hanselifter.de

Manufacturer Location

Bremen

Manufacturer name

Gesutra GmbH

Manufacturer Postcode

28219

Manufacturer Street & house number

Straubinger Str. 20

Product safety instructions

Ensure that the pallet truck is operated on a level and stable surface to prevent it from tipping over.;Do not exceed the maximum load capacity of 2 tonnes to avoid overloading and damage.;Wear suitable personal protective equipment (PPE) such as safety shoes and gloves.;Check the product regularly for wear, damage and mechanical damage.;The load may only be lowered when the pallet truck is stationary.;Take particular care when handling and transporting heavy loads and ensure that you have a clear view.;Do not operate the product in explosive or flammable atmospheres.;Do not use for the transport of people.;Users of the pallet truck must be trained to avoid injuries.;Before use, check the hydraulic unit and hydraulic pump for leaks and proper functioning.;Ensure that the fork rollers and castor wheels function properly and are maintained to prevent tipping.;Secure the load properly to prevent it from slipping.;Regular maintenance required to ensure safety.;Suitable for use with standardised pallets.;Do not leave the product unattended when tilted.

Article numbers

305032 305033 305034 305035 305036 305037 305038 305039 305040 305041 305042 305043 305044

DB700 Forklift

Name: DB700 Forklift
Brand: Hanselifter
SKU: 7476034
Price: 729.0 CHF
Availability: InStock

Item number: 305040

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

They have a load capacity of 2 t. All DB series pallet trucks are equipped with polyurethane fork rollers and swivel wheels as standard.
Equipment features

High-quality powder coating and robust construction
Grease nipple for easy maintenance
Quality hydraulic pump
Pressure relief valve for a long service life
Metered, stepless lowering using the hand lever
Extension and retraction rollers and fork markings for easy transverse pallet pick-up
Load capacity: 2.0 t
Model DB450:

Fork outer distance: 520 mm, L 825 x W 520 x H 1180 mm, 42 kg, castors: PU/PU single, turning radius: 730 mm

Model DB500:

Outer fork spacing: 520 mm, L 875 x W 520 x H 1180 mm, 46 kg, castors: PU/PU single, turning radius: 780 mm

Model DB600:

Fork outer distance: 520 mm, L 975 x W 520 x H 1180 mm, 48 kg, castors: PU/PU single, turning radius: 840 mm

Model DB700:

Fork outer distance: 520 mm, L 1075 x W 520 x H 1180 mm, 61 kg, castors: PU/PU single, turning radius: 965 mm

Model DB800:

Fork outer distance: 540 mm, L 1200 x W 520 x H 1180 mm, 63 kg, castors: PU/PU single, turning radius: 1060 mm

Model DB800t:

Outer fork spacing: 520 mm, L 1175 x W 520 x H 1180 mm, 65 kg, castors: PU/PU tandem, turning radius: 1060 mm

Model DB600685:

Fork outer distance: 685 mm, L 1000 x W 685 x H 1230 mm, 67 kg, castors: PU/nylon single, turning radius: 860 mm

Model DB800450:

Fork outer distance: 450 mm, L 1220 x W 450 x H 1200 mm, 60 kg, castors: PU/PU single, turning radius: 950 mm

Model DB800480:

Fork outer spacing: 480 mm, L 1175 x W 480 x H 1180 mm, 55 kg, castors: PU/PU Single, turning radius: 950 mm

Model DB1000450:

Fork outer spacing: 450 mm, L 1375 x W 450 x H 1240 mm, 65 kg, castors: PU/PU tandem, turning radius: 1140 mm

Model DB1000480:

Fork outer distance: 480 mm, L 1375 x W 480 x H 1180 mm, 60 kg, castors: PU/PU tandem, turning radius: 1140 mm

Model DB1150450:

Fork outer distance: 450 mm, L 1525 x W 450 x H 1240 mm, 68 kg, castors: PU/PU tandem, turning radius: 1280 mm

Model DB1150480:

Fork outer distance: 480 mm, L 1525 x W 480 x H 1180 mm, 60 kg, castors: PU/PU tandem, turning radius: 1280 mm

Advantages for you

Easy handling thanks to lift drive

Thanks to a lifting range of 75 - 190 mm, the pallet truck can transport loads over uneven floors

Show moreShow less

Technical data

General features
Color of the pull-up bar black
Colour fork blue
Delivery Mounted
Design of fork wheels Polyurethane
Diameter of the load rollers (mm) 70
Diameter swivel castors [mm] 160
External fork spacing [mm] 520
Fork dimensions L/W/H [mm] 700/150/50
Fork length [mm] 700
Fork width [mm] 520
Lift drive manually
Load capacity [kg] 2000
Load capacity [kg] 2000
Manufacturer No. 11002687
Material Swivel castors Polyurethane (PU)
Minimum height 25
Model DB700
Steering angle [°] 210
Steering wheel design Tandem
Steering wheels material Polyurethane (PU)
Stroke range [mm] 75 - 190
Swivel castor version Tandem
Total height [mm] 1180
Total length (mm) 1075
Total width [mm] 520
Turning radius [mm] 965
Weight [kg] 61
Colors
Color blue

Schäfer Shop Quality and Service

only Fr. 729.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Fork dimensions L/W/H [mm]: 700/150/50 mm

1000/160/60 mm 1000/150/50 mm 1150/160/60 mm 1150/150/50 mm 450/150/50 mm 500/150/50 mm 600/150/50 mm 700/150/50 mm 800/150/50 mm

Model: DB700

DB1000450 DB1000480 DB1150450 DB1150480 DB450 DB500 DB600 DB700 DB800

Stroke range [mm]: 75 - 190 mm

85 - 200 mm 75 - 190 mm

show all variants

Add to basket

Delivery time: within 3 weeks

Purchase on account available
Secure and fast payment

Our recommendations for you

Variants

Overview of variants - Lifting truck DB in special dimensions

Overview of the possible item variants. For more information, click on the respective variant.

Fork dimensions L/W/H [mm]

Model

Stroke range [mm]

Item			Price
Trolley DB1000450 Item number: 305032			Fr. 1’099.00 Amount + - Added times
Trolley DB1000480 Item number: 305033			Fr. 879.00 Amount + - Added times
Trolley DB1150450 Item number: 305034			Fr. 1’049.00 Amount + - Added times
Trolley DB1150480 Item number: 305035			Fr. 879.00 Amount + - Added times
DB450 Forklift Item number: 305036			Fr. 729.00 Amount + - Added times
DB500 Forklift Item number: 305037			Fr. 729.00 Amount + - Added times
DB600 Forklift Item number: 305038			Fr. 729.00 Amount + - Added times
DB700 Forklift Item number: 305040			Fr. 729.00 Amount + - Added times
DB800 Forklift Item number: 305041			Fr. 579.00 Amount + - Added times
