Product Safety Information

CEMO battery charging cabinet Basic 8/10, 1-phase, 2 x 6-socket power strips, ventilated, 2 smoke detectors, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange

General information

EU authorized representative E-mail address

kontakt@cemo-group.com

EU authorized representative Name

CEMO GmbH

EU authorized representative Place

Weinstadt

EU authorized representative Postal code

71384

EU authorized representative Street & house number

In den Backenländern 5

EU Plenipotentiary Country

Deutschland

Product safety instructions

Risk of suffocation due to improper handling or improper storage of rechargeable batteries.;Always read and follow the instructions and safety information before use. Read the user manual carefully before use.;Activate automatic safety shutdown in the event of faults or malfunctions. Do not bypass automatic switch-off in the event of a fault.;Check smoke detectors regularly to ensure that they are working properly.;Do not overload the oven. Do not exceed the maximum capacity.;Only use with the socket strips provided.;Do not use the devices in the cabinet while they are charging.;Observe safety precautions when using the charger.;Before servicing or charging the battery, ensure that the charging cabinet is switched off.;Keep small parts and electrical components out of the reach of children.

Article numbers

662677 662688

CEMO battery charging cabinet Basic 8/10, 1-phase, 2 x 6-socket power strips, ventilated, 2 smoke detectors, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange

Name: CEMO battery charging cabinet Basic 8/10, 1-phase, 2 x 6-socket power strips, ventilated, 2 smoke detectors, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange
Brand: Cemo
SKU: 8590111
Price: 4415.0 CHF
Availability: InStock

Item number: 662688

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

Battery charging cabinet When charging lithium batteries, fire protection is a high priority. CEMO has been offering a safe solution since 2020, developing it further in line with the latest findings and obtaining the latest certifications. Equipped with important safety features, the fire consequences of these energy storage systems can be reduced to a minimum and operational safety significantly increased. - charging several lithium batteries in the cabinet - early alarm in the event of damage - all relevant safety rules for charging lithium batteries are complied with - ideal for shielding batteries from the stored stock during the charging process - can also be used as an underbench cabinetTÜV NORD Group verification through the latest test program with real battery fire tests and induced gas explosions - MPA-tested fire resistance over 60 minutes from the inside to the outside in accordance with DIN EN 1363-1 - construction with non-combustible, fire-resistant components - NEW fire-resistant components - NEW: Spring-based CEMO lockEX door lock for controlled pressure relief in the event of explosions - Special fire protection seals prevent flames from escaping - Cold smoke-tight closure system for openings - Transportable for positioning at the installation site - Double-leaf, lockable doors with sturdy locking & suspension - Door finish in orange, similar to RAL 2004; body in gray, similar to RAL 7035

Show moreShow less

Technical data

General features
Accessible from below Yes
Body colour light grey RAL 7035
Color pure orange RAL 2004
Delivery Mounted
Depth [mm] 660
Door type Gullwing door
Equipment Battery-operated acoustic smoke detector, 2x 6-socket power strip, 1 socket outlet, feet
Fire resistance 60 minutes
Fire resistance class Type 60
GS-approved No
Hazardous material class Lithium-ion batteries
Hazardous substance type Lithium-ion batteries
Height [mm] 1110
Inner height [mm] 840
Inside depth (mm) 530
Inside width [mm] 730
Insulation No
Location Indoor
Lock Cylinder lock
Lockable Yes
Material Gypsum and cellulose fibers
Material body Steel
Number of door(s) 2
Number of shelves [pcs.] 1
Scope of delivery Battery charging cabinet;Power strip;Smoke detector
Surface HPL coating
Ventilation Fan
Version 1-phase: 230 V
Weight [kg] 135
Width [mm] 800

Download

ProductSafety_10176502.pdf

Schäfer Shop Quality and Service

only Fr. 4’415.00

per

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Version: 1-phase: 230 V

3-phase: 400 V 1-phase: 230 V

show all variants

Add to basket

Delivery time: approx. 6 weeks

Purchase on account available
Secure and fast payment

Variants

Overview of variants - CEMO Basic 8/10 battery charging cabinet, 2 x 6-socket power strips, ventilated, 2 smoke detectors, 1-phase or 3-phase, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange

Overview of the possible item variants. For more information, click on the respective variant.

Version

Item			Price
CEMO battery charging cabinet Basic 8/10, 3-phase, 2 x 6-socket power strips, ventilated, 2 smoke detectors, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange Item number: 662677			Fr. 4’535.00 Amount + - Added times
CEMO battery charging cabinet Basic 8/10, 1-phase, 2 x 6-socket power strips, ventilated, 2 smoke detectors, with feet, W 800 x D 660 x H 1110 mm, light gray/pure orange Item number: 662688			Fr. 4’415.00 Amount + - Added times
No results

Accessories

Item			Price
Aerosol extinguisher for CEMO battery storage and charging cabinets, rapid flame suppression, automatic triggering, maintenance-free, for up to 0.25 m³ Item number: 662669			only Fr. 479.00 from Fr. 479.00 per null - + Added times
CEMO wireless heat and smoke alarms, set of 2, battery-operated, networkable, incl. 2 magnetic plates and batteries Item number: 662673			only Fr. 167.00 from Fr. 167.00 per null - + Added times
Shelf for CEMO battery storage and charging cabinets, steel, W 720 x D 400 x H 35 mm, light gray RAL 7035 Item number: 662686			only Fr. 179.00 from Fr. 179.00 per null - + Added times
