Product Safety Information

Firefighter locker C+P Evolo Flexo, 1 compartment, helmet holder, with base, W 500 x D 500 x H 1950 mm, RAL 7016 anthracite gray/RAL 7021 black gray

General information

EU authorized representative E-mail address

info@cp.de

EU authorized representative Name

C+P Möbelsysteme GmbH & Co. KG

EU authorized representative Place

Breidenbach

EU authorized representative Postal code

35236

EU authorized representative Street & house number

Boxbachstraße 1

EU Plenipotentiary Country

Deutschland

Product safety instructions

Provision of safety information for the safe use of the product.;Handle the product with care to avoid injury.;Regularly check the locker for visible damage and corrosion. If damage is detected, take the locker out of operation immediately.;Stable location of the locker to prevent it from tipping over. Mention the stable base repeatedly.;Ventilation openings must not be blocked to prevent mould and odours from forming. Regular inspection and ventilation necessary.;Only use the locker for its intended purpose in order to avoid damage and risk of injury.;Ensure that children do not have unsupervised access to the locker.;Observe the manufacturer's instructions for using the cylinder lock and check the locks regularly to prevent unauthorised access.;Avoid direct sunlight to minimise material damage caused by UV radiation.;Do not use chemical cleaning agents or abrasive materials. Keep clean and dry to prevent corrosion.;Dispose of defective or damaged parts in accordance with local regulations.;The locker is not suitable for the safe storage of hazardous substances.;Do not store any flammable materials or valuables in the locker. Consider additional safety measures.;Ensure the use of suitable materials in accordance with the safety regulations for firefighting equipment.;Regular inspection and maintenance of the locker is recommended to ensure safety and functionality.;Ensure that the doors are ventilated to prevent mould growth and do not use the locker as a play area if children are using it.;Users should keep the cylinder key in a safe place.;Sharp edges on the construction can cause injuries.

Article numbers

406773 406774 406775 406785 406786 406787 406797 406798 406799 406809 406810 406811 406821 406822 406823 406833 406834 406835

Firefighter locker C+P Evolo Flexo, 1 compartment, helmet holder, with base, W 500 x D 500 x H 1950 mm, RAL 7016 anthracite gray/RAL 7021 black gray

Item number: 406774

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

Experience maximum functionality and quality with the Evolo Flexo firefighter locker from C+P. This locker is specially designed to meet the needs of firefighters and impresses with its well thought-out features and robust construction.

The Evolo Flexo firefighter locker offers a spacious compartment with a width of 500 mm, which provides sufficient space for your firefighting equipment. Thanks to built-in ventilation openings at the top and bottom in the rear area, optimum ventilation of your clothing and equipment is ensured. The interior of the locker is designed for high functionality. On the one hand, the locker has a sturdy oval profile coat rail and 5 anti-twist sliding hooks. On the other hand, it is equipped with a valuables box with a slot, a shortened helmet shelf and a foldable helmet holder. A multifunctional hook strip on the side with 3 sliding stainless steel hooks offers additional space for safety harnesses, lifelines and other equipment. The cylinder lock provides a high level of security.

Made from a sturdy steel construction and finished with a high-quality stove enamel coating, the locker is particularly UV and corrosion resistant. The dimensions of the locker are W 500 x D 500 x H 1950 mm. With its elegant color scheme, the Evolo Flexo firefighter locker from C+P blends seamlessly into any room concept. The body and doors are in RAL 7016 anthracite gray and the base in RAL 7021 black gray.

Important details:

Fire department locker with one compartment
Compartment width 500 mm
Electrolytically galvanized foot section
Can be swept out smoothly
With rear ventilation openings at the top and bottom
Equipment:
- One sturdy coat rail made of oval profile with 5 anti-twist sliding hooks
- One valuables box with insertion opening
- A shortened helmet base (for kink-free storage of the neck guard)
- A foldable plastic helmet holder
- A lateral multifunctional hook strip with 3 sliding stainless steel hooks each for safety harness, lifeline, etc.
One cylinder lock with 2 keys
Locking range up to 1000 different locks
With base
Body made of sturdy steel construction with high-quality stove-enamel coating for high UV and corrosion resistance
Dimensions: W 500 x D 500 x H 1950 mm
Color:
- Body: RAL 7016 anthracite gray
- Doors: RAL 7016 anthracite gray
- Feet: RAL 7021 black gray

Advantages for you

Saves a lot of space in small rooms with dimensions of 500 x 1950 mm

Show moreShow less

Technical data

General features
Adjustment travel level control 25
Clear internal height of other compartment [mm] 185
Closing circuit up to 1000
Coat rail fixed
Color base RAL 7016 anthracite gray
Door height [mm] 165
Door opening angle (°) 110
Door stop right
Door version open / with valuables compartment
Door width [mm] 118
Equipment Checkroom rail, helmet holder, hook rail
Helmet bottom shortened
Helmet holder Yes
Hook bar fixed
Insertion slot Yes
Key type Beard key
Level control Yes
Lockable Yes
Locking system Cylinder lock
Material Steel
Material coat hook Plastic
Material coat rack Plastic
Material helmet holder Plastic
Material hook Stainless steel
Material hook bar Plastic
Material substructure Steel
Model FLEXO
Number of compartments [pcs.] 1
Number of door(s) 1
Number of hooks [pcs.] 3
Number of keys [pcs.] 2
Profile coat rack oval
Profile hook strips oval
Substructure Base
Substructure height [mm] 100
Surface varnished
Surface substructure lacquered
Tipping dimension [MMT] 1916
Value compartment depth [mm] 377
Value compartment height [mm] 178
Value compartment width [mm] 173
Ventilation Perforated strip in cabinet bottom/headboard
Ventilation hole pattern front No
Version helmet holder foldable
Wardrobe height [mm] 1325
Weight [kg] 18.44
Colors
Color anthracite grey RAL 7016
Dimensions
Clear inside depth [mm] 477
Clear inside width [mm] 499
Clear internal height of bottom compartment [mm] 1421
Clear internal height of top compartment [mm] 365
Compartment width (mm) 500
Depth [mm] 500
Dimensions W x D x H [mm] 500 x 500 x 1950
Height [mm] 1950
Width [mm] 500

Schäfer Shop Quality and Service

Special features of this product

only Fr. 879.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Color: anthracite grey RAL 7016

light grey RAL 7035 anthracite grey RAL 7016 fire red RAL 3000

Depth [mm]: 500 mm

500 mm 600 mm

Width [mm]: 500 mm

500 mm 1000 mm

show all variants

Add to basket

Delivery time: within 4 weeks

Purchase on account available
Secure and fast payment
