Product Safety Information

Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray

General information

EU authorized representative E-mail address

info@cp.de

EU authorized representative Name

C+P Möbelsysteme GmbH & Co. KG

EU authorized representative Place

Breidenbach

EU authorized representative Postal code

35236

EU authorized representative Street & house number

Boxbachstraße 1

EU Plenipotentiary Country

Deutschland

Product safety instructions

Mount the locker stably and securely on a flat surface to prevent it from falling over.;Do not block the ventilation openings to ensure sufficient air circulation and hygiene.;Avoid contact with water and damp conditions to prevent corrosion.;Do not overload to maintain structural integrity and stability. Max. Observe maximum weight.;Use the locker in accordance with the manufacturer's instructions; avoid improper use.;Keep the cylinder lock and key in a safe place; do not allow children access.;Ensure that doors are properly closed and locked to prevent unauthorised access.;Carry out regular inspections for damage and wear; replace weak or damaged parts immediately.;Prevent the storage of highly flammable or sharp materials in the locker to minimise the risk of fire and injury.;Sharp edges and corners: handle with care to avoid injury.;To avoid injury, do not allow children to use the locker as play equipment.;The steel doors have locking mechanisms that must be checked regularly to prevent unauthorised opening.;Take care when using the locker for protective equipment to avoid the risk of crushing.;Avoid danger of suffocation: Prevent improper storage of small parts in the compartments and use as a toy.;Use by adults only; children should not play unsupervised near the locker.;Ensure provision of clear instructions and safety information.

Article numbers

407061 407062 407063 407073 407074 407075 407085 407086 407087 407097 407098 407099

Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray

Name: Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray
Brand: C + P
SKU: 7527289
Price: 1949.0 CHF
Availability: InStock

Item number: 407099

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

The Evolo Maxi firefighter locker from C + P is an excellent storage solution for two people. It complies with DIN 14092 / DGUV standards and offers two separate compartments per person to allow separate storage of work and private clothing.

Each person has a compartment with a width of 500 mm for their work clothes. Each compartment is equipped with a valuables box with a slot, a sturdy clothes rail with anti-twist sliding hooks, a shortened helmet shelf, a helmet holder and multifunctional hook rails on the sides. In addition, each person has a compartment with a width of 300 mm for private clothing. Each compartment has a sturdy coat rail and two anti-twist sliding hooks. The door of each compartment is made of steel and is fitted with a cylinder lock and two keys. The locker has ventilation openings at the top and bottom for efficient ventilation.

Despite its generous footprint of W 1300 x D 600 x H 1950 mm, the locker remains compact. With its functional and robust design in RAL 3000 fire red (body and doors) and RAL 7016 anthracite gray (base), the Evolo Maxi firefighter locker from C + P has a simple yet modern look.

Important details:

Firefighter locker with 4 compartments for two people
2 compartments per person for separate storage of work and private clothing in accordance with DIN 14092 / DGUV
Compartment width:
- 500 mm each on the left and right
- 300 mm in the middle
Body made of sturdy steel construction with high-quality stove-enamel coating for high UV and corrosion resistance
Electrolytically galvanized foot section
Can be swept out smoothly
With rear ventilation openings at the top and bottom
Compartment equipment (left and right) per person:
- Valuables compartment box with insertion opening
- 1 sturdy wardrobe rail made of oval profile with 5 anti-twist sliding hooks
- 1 shortened helmet base, for kink-free storage of the neck protector
- 1 foldable plastic helmet holder
- 1 lateral multifunctional hook rail with 3 sliding stainless steel hooks each for safety harness, lifeline, etc.
2 compartments in the middle section:
- 1 sturdy oval profile coat rail with 2 anti-twist sliding hooks per compartment
- One steel door per compartment with closed side profiles for maximum stability
- One cylinder lock with 2 keys per steel door, locking circle up to 1000 different locks
With plinth
Dimensions: W 1300 x D 600 x H 1950 mm
Color:
- Body: RAL 3000 fire red
- Doors: RAL 3000 fire red
- Feet: RAL 7016 anthracite gray

Advantages for you

The generous dimensions of 1300 x 1950 mm allow you to accommodate many garments

Show moreShow less

Technical data

General features
Adjustment travel level control 25
Clear inside width right [mm] 499
Clear internal height of other compartment [mm] 185
Closing circuit up to 1000
Coat rail fixed
Color base RAL 7016 anthracite gray
Door height [mm] 165
Door opening angle (°) 110
Door stop right/left
Door version Hinged doors
Door width [mm] 118
Equipment Checkroom rail, helmet holder, hook rail
Fastening lettering imprinted
Fitting front inside
Helmet bottom shortened
Helmet holder Yes
Hook bar fixed
Insertion slot Yes
Key type Beard key
Level control Yes
Lockable Yes
Locking system Cylinder lock
Material Steel
Material coat hook Plastic
Material coat rack Plastic
Material helmet holder Plastic
Material hook Stainless steel
Material hook bar Plastic
Material substructure Steel
Model MAXI
Number of compartments [pcs.] 4
Number of door(s) 2
Number of hooks [pcs.] 3
Number of keys [pcs.] 2
Profile coat rack oval
Profile hook strips oval
Standard DIN 14092 / DGUV
Substructure Base
Substructure height [mm] 100
Surface varnished
Surface substructure lacquered
Tipping dimension [MMT] 1945
Type of suspension Pivot bolt
Value compartment depth [mm] 377
Value compartment height [mm] 178
Value compartment width [mm] 173
Ventilation Perforated strip in cabinet bottom/headboard
Ventilation hole pattern front Yes
Version helmet holder foldable
Wardrobe height [mm] 1325
Weight [kg] 47.62
Colors
Color fire red RAL 3000
Dimensions
Clear inside depth [mm] 577
Clear inside width [mm] 299
Clear internal height of bottom compartment [mm] 1421
Clear internal height of top compartment [mm] 365
Compartment width (mm) 500+300
Depth [mm] 600
Dimensions W x D x H [mm] 1300 x 600 x 1950
Height [mm] 1950
Width [mm] 1300

Schäfer Shop Quality and Service

Special features of this product

only Fr. 1’949.00

per Pcs.

excl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF 8.90.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Color: fire red RAL 3000

light grey RAL 7035 anthracite grey RAL 7016/anthracite grey RAL 7016 fire red RAL 3000 anthracite grey RAL 7016

Depth [mm]: 600 mm

500 mm 600 mm

Width [mm]: 1300 mm

1200 mm 1300 mm

show all variants

Add to basket

Delivery time: within 4 weeks

Purchase on account available
Secure and fast payment

Our recommendations for you

Variants

Overview of variants - C+P Fire brigade locker Evolo, model MAXI, base

Overview of the possible item variants. For more information, click on the respective variant.

Color

Depth [mm]

Width [mm]

Item			Price
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1200 x D 500 x H 1950 mm, RAL 7035 light gray/RAL 7016 anthracite gray Item number: 407061			Fr. 1’649.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 persons, with helmet holder, with base, W 1200 x D 500 x H 1950 mm, RAL 7016 anthracite gray Item number: 407062			Fr. 1’649.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1200 x D 500 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray Item number: 407063			Fr. 1’649.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 500 x H 1950 mm, RAL 7035 light gray/RAL 7016 anthracite gray Item number: 407073			Fr. 1’699.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 persons, with helmet holder, with base, W 1300 x D 500 x H 1950 mm, RAL 7016 anthracite gray Item number: 407074			Fr. 1’699.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 500 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray Item number: 407075			Fr. 1’699.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1200 x D 600 x H 1950 mm, RAL 7035 light gray/RAL 7016 anthracite gray Item number: 407085			Fr. 1’849.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 persons, with helmet holder, with base, W 1200 x D 600 x H 1950 mm, RAL 7016 anthracite gray Item number: 407086			Fr. 1’849.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 persons, with helmet holder, with base, W 1200 x D 600 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray Item number: 407087			Fr. 1’849.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 7035 light gray/RAL 7016 anthracite gray Item number: 407097			Fr. 1’949.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 7016 anthracite gray Item number: 407098			Fr. 1’949.00 Amount + - Added times
Firefighter locker C+P Evolo Maxi, 4 compartments for 2 people, with helmet holder, with base, W 1300 x D 600 x H 1950 mm, RAL 3000 fire red/RAL 7016 anthracite gray Item number: 407099			Fr. 1’949.00 Amount + - Added times
