Product Safety Information

Assembly ladder, with aluminium grating steps, 2 steps

General information

Product safety instructions

Do not exceed the maximum working height.;Check for stability and safe standing before use.;Ensure that the assembly step is not overloaded and observe the maximum working height and load capacity.;Only use the assembly step on stable, stable and level surfaces.;Ensure that steps are clean and dry to avoid the risk of slipping and take suitable measures to prevent slipping.;Do not use an assembly step if it is damaged or defective.;Keep out of the reach of children to prevent accidents (observe child safety lock).;Wear suitable safety shoes to minimise the risk of injury.;Observe the safety precautions for electrical applications.;Avoid use in poor lighting conditions.;Use by adults only.;When ascending and descending, always hold on tight and move slowly.;Observe the TÜV/GS test; nevertheless check regularly for damage or wear.;Regularly check the anti-slip properties of the grating steps for wear.

Article numbers

95467 95468 95469 95470 95471

Assembly ladder, with aluminium grating steps, 2 steps

Item number: 95468

Click on image for larger view Click on image for larger view

360° view

Show moreShow less

Product description

The assembly step is suitable for use in workplaces where substances that promote slipping occur or work areas with an increased risk of slipping. The grating steps with serrated support bar tops, which meet the highest requirement (evaluation group R13 according to BGR 181) for slip resistance, offer even more safety. The assembly step is also TÜV/GS tested.
1 step: working height up to: approx. 2200 mm, platform height: 200 mm, weight: 2.5 kg2
steps
:
Working height up to: approx. 2400 mm, platform height: 400 mm, weight: 5.4 kg3
steps
:
Working height up to: approx. 2600 mm, platform height: 600 mm, weight: 8.0 kg4
steps
:
Working height up to: approx. 2800 mm, platform height: 800 mm, weight: 11.0 kg5
steps
:
Working height up to: approx. 3000 mm, platform height: 1000 mm, weight: 13.5 kg

Advantages for you

Suitable for everyday use in the office and requires only little storage space with a height of 400 mm

Show moreShow less

Technical data

General features
Color silver
Delivery Mounted
Foldable No
GS-approved Yes
Height (m) 0.4
Height [mm] 400
Load capacity [kg] 150
Material Aluminium
Material folding step Aluminium
Material platform Aluminium
Max. load capacity (kg) 150
Mobile No
Number of rungs 2
Number of steps [pcs.] 2
Platform length(mm) 305
Platform surface anti-slip
Platform width [mm] 520
Standard EN 14183
Step depth (mm) 240
Steps 2
Surface step anti-slip
Version Grating steps
Version folding step top teeth of beams
Weight [kg] 10
Working height (m) 2,4

Download

ProductSafety_10036961.pdf

Schäfer Shop Quality and Service

Special features of this product

only Fr. 522.10

per Pcs.

Incl. VAT free shipping from CHF 100.–

Enjoy free shipping from CHF 100.–. For smaller orders, shipping costs CHF9.60.
General terms and conditions

This feature is not compatible with your previous selection. You can reset your selection by clicking on it. Please select

Steps: 2

1 2 3 4 5

show all variants

Add to basket

Delivery time: within 2 weeks

Secure and fast payment

Variants

Overview of variants - Assembly steps, with aluminium grating steps

Overview of the possible item variants. For more information, click on the respective variant.

Steps

Item			Price
Assembly ladder, with aluminium grating steps, 1 step Item number: 95467			Fr. 271.35 Amount + - Added times
Assembly ladder, with aluminium grating steps, 2 steps Item number: 95468			Fr. 522.10 Amount + - Added times
Assembly ladder, with aluminium grating steps, 3 steps Item number: 95469			Fr. 726.45 Amount + - Added times
Assembly ladder, with aluminium grating steps, 4 steps Item number: 95470			Fr. 976.15 Amount + - Added times
Assembly ladder, with aluminium grating steps, 5 steps Item number: 95471			Fr. 1’135.05 Amount + - Added times
